Siemens HF362N - Fusible Disconnect Switch, 60A 600V 3-Pole

Siemens
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens HF362N is a fusible disconnect switch designed for providing visible isolation and overcurrent protection in industrial power distribution systems. It is rated for 600V AC operation with a 60A current rating and features a 200kA interrupting capacity at 600V for robust short-circuit protection. The switch is constructed with a NEMA 1 enclosure measuring 16.62 x 10.37 x 8.67 inches and weighing 18.001 lb, and it operates reliably within a temperature range of -25°C to 70°C (-13°F to 158°F). This UL-listed, 3-pole device is part of the VBII series and is compatible with PGP frames, ensuring compliance with industry standards for safety and interoperability. Its typical applications include motor control centers and main feeder disconnects where a fusible switch configuration with Class R fuses is required.

Key Features & Specifications
  • Type: Fusible Disconnect Switch, VBII Series, Single Configuration
  • Voltage Rating: 600V AC
  • Current Rating: 60A
  • Dimensions: 16.62 x 10.37 x 8.67 inch
  • Weight: 18.001 lb
  • Standards: UL listed
  • Applications: Industrial power distribution, motor control centers, main feeder disconnects
  • Switch Type: Fusible
  • Configuration: Single
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 3
  • AIC rating: 200kA@600V
  • Poles: 3
  • Fuse Class: R
  • Nema Rating: NEMA 1
  • Compatible Frames: PGP
  • Enclosure: NEMA 1


Product Identification
  • UPC: 783643151093
  • GTIN: 00783643151093
