Siemens HF322S - Fusible Disconnect Switch 60A@240V (NEMA 4X Enclosure)

Siemens HF322S is a fusible safety disconnect switch designed for industrial power distribution systems requiring reliable circuit protection. The unit operates at 240V AC with a 60A current rating, featuring a rugged NEMA 4X-rated enclosure for harsh environments. Its 3-pole single configuration with Class R fuses provides 200kA interrupting capacity at 240V, housed in a corrosion-resistant 11.5" x 17.5" enclosure weighing 30 lb. UL-listed and compatible with NS frames, this disconnect is engineered for three-phase applications requiring durable overcurrent protection in manufacturing plants and heavy machinery installations.

Key Features & Specifications

• Type: Fusible safety disconnect switch with Class R fuse protection
• Voltage Rating: 240V AC
• Current Rating: 60A
• Dimensions: 11.5 in x 17.5 in (292.1 mm x 444.5 mm)
• Standards: UL listed, NEMA 4X
• Applications: Industrial power distribution, heavy machinery
• Configuration: Single
• Poles: 3
• AIC rating: 200kA@240V
• Switch Style: Fusible
• Phase: 3
• Fuse Class: R
• Wire: 3
• Compatible Frames: NS
• Weight: 30 lb (13.6 kg)
• Country of Origin: Mexico

Product Identification

• UPC: 783643150942
• GTIN: 00783643150942
