Siemens
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens HF322NR is a fusible disconnect switch designed for providing a visible break and overcurrent protection in three-phase industrial power distribution systems. It features a 240V AC voltage rating and a 60A current rating, housed within a robust NEMA 3R enclosure measuring 16.93 x 10.41 x 9.21 inches and weighing 19 lb for durability in demanding environments. The switch is UL listed and offers a high interrupting capacity of 200kA at 240V, ensuring reliable protection and compliance with industry safety standards. Its design, part of the VBII Series, is suitable for applications requiring a 3-pole, single-configuration disconnect with R-class fuse compatibility, operating effectively in temperatures from -25°C to 70°C.

Key Features & Specifications
  • Type: Fusible Disconnect Switch, HF type, single configuration
  • Voltage Rating: 240V AC
  • Current Rating: 60A
  • Dimensions: 16.93 x 10.41 x 9.21 inches (430 x 264 x 234 mm)
  • Standards: UL listed, NEMA 3R enclosure rating
  • Applications: Industrial power distribution, motor control, panel protection
  • Switch Style: Fusible
  • Configuration: Single
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Shipping Dimensions: 16.93 x 10.41 x 9.21 inches
  • Phase: 3
  • Voltage: 240V AC
  • Amperage: 60A
  • AIC rating: 200kA at 240V
  • Connection: Not specified
  • Poles: 3
  • Protection: Overcurrent via R-class fuses
  • Functions: Disconnect and fuse protection
  • Frame Size: Not specified
  • Trip Type: Not applicable
  • Panel Type: Not specified
  • Breaker Type: Not applicable
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not specified
  • Metal Type: Not specified
  • Panel Style: Not specified
  • Bus Type: Not specified
  • Fuse Class: R
  • Insulation Temperature: Not specified
  • Inductance: Not applicable
  • Impedance: Not applicable
  • Barrels: Not applicable
  • Class Rating: Not specified
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not specified
  • Mounting: Not specified
  • Hz: 50/60 Hz typical
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: Not specified
  • Dist Voltage: Not specified
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: Not specified
  • Full Load Amp Minimum: Not specified
  • Enclosure: NEMA 3R
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Not specified
  • Amperage Maximum: 60A
  • Amperage Minimum: Not specified
  • Nema Rating: NEMA 3R
  • Switch Style: Fusible
  • Wire Size: Not specified
  • Certification: UL listed
  • Circuit Breaker Mounting Style: Not applicable
  • Terminal Connection: Not specified
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-phase
  • Standards: UL
  • Compatible Frames: VBII Series
  • Installation Type: Not specified
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: Not applicable
  • Current Rating: 60A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not specified
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 70°C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 783643150690
  • GTIN: 00783643150690
