Siemens HF263J - Fusible Disconnect Switch, 100A 600V 2-Pole

Siemens
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens HF263J is a fusible disconnect switch designed for providing visible isolation and overcurrent protection in industrial power distribution systems. It is rated for 600V AC operation with a continuous current rating of 100A and features a 200kA interrupting capacity at 600V for robust short-circuit protection. The switch is constructed within a NEMA 12 enclosure measuring 14.961 x 7.874 x 27.953 inches and weighing 26.345 lb, and it is designed for use with Class R fuses. This UL-listed component complies with industry standards and is part of the VBII Series, compatible with MXP frames. Its typical applications include motor control centers and main feeder disconnects where reliable circuit isolation and protection are required.

Key Features & Specifications
  • Type: Fusible Disconnect Switch, VBII Series
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Configuration: Single
  • Poles: 2
  • Phase: 1
  • AIC Rating: 200kA @ 600V
  • Fuse Class: R
  • NEMA Rating: NEMA 12
  • Switch Style: Fusible
  • Dimensions: 14.961" x 7.874" x 27.953"
  • Weight: 26.345 lb
  • Standards: UL Listed
  • Compatible Frames: MXP
  • Applications: Industrial power distribution, motor control centers, main feeder disconnects


Product Identification
  • UPC: 783643174023
  • GTIN: 00783643174023
