Square D HDM36100U33X - Molded Case 100A 600V (3-Pole Solid State)
Square D HDM36100U33X - Molded Case 100A 600V (3-Pole Solid State)

Square D HDM36100U33X - Molded Case 100A 600V (3-Pole Solid State)

Square D
Price
Save $703.69
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Square D HDM36100U33X is a 3-pole molded case circuit breaker from the Powerpact family, designed for overcurrent protection in industrial power distribution systems. It features a solid-state trip unit with LSI (Long Time, Short Time, and Instantaneous) protection functions, rated for 100A continuous current at 600V AC, with an interrupting capacity of 18kA at 480V. The unit weighs 5 lb and uses a bolt-on connection for secure panel mounting, supporting 3-phase systems. It complies with applicable industry standards for molded case circuit breakers. Typical applications include motor control centers, switchboards, and industrial panelboards requiring precise adjustable protection settings.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Solid State Trip
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Poles: 3
  • Phase: 3
  • Connection: Bolt-On
  • Protection: LSI - Long Time, Short Time and Instantaneous
  • AIC Rating: 18kA@480V
  • Weight: 5 lb
  • Family: Powerpact
  • Type: HDM


Product Identification
  • GTIN: 00785901497035
