Square D HDL26060 - Molded Case Circuit Breaker 60A 600V 2-Pole
Square D HDL26060 - Molded Case Circuit Breaker 60A 600V 2-Pole

Square D HDL26060 - Molded Case Circuit Breaker 60A 600V 2-Pole

Square D
Price
Save $424.06
/
Condition
  • Low stock - 10 items left
  • Backordered, shipping soon
Call for Price
Square D HDL26060 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial power distribution systems. It features a 60A current rating and a 600V voltage rating, housed within a compact 150A/HD frame measuring 163 mm x 104 mm x 86 mm (H x W x D) with a bolt-on connection for secure installation. This thermal magnetic breaker complies with UL, CSA, NEMA, and IEC 60947-2 standards, ensuring robust performance and safety. It is typically applied in single-phase applications for protecting feeders and branch circuits, with an interrupting capacity of 18kA at 480V and an operational temperature range of -2 to 70 °C.

Key Features & Specifications
  • Type: Standard thermal magnetic molded case circuit breaker with long-time and instantaneous (LI) trip functions
  • Voltage Rating: 600V AC
  • Current Rating: 60A
  • Dimensions: 163 mm H x 104 mm W x 86 mm D (6.4 in x 4.09 in x 3.4 in)
  • Weight: 3 lb
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial power distribution for feeder and branch circuit protection
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -2 to 70 °C (28 to 158 °F)
  • Phase: 1
  • AIC Rating: 18kA @ 480V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI)
  • Frame Size: 150A/HD
  • Breaker Type: Standard
  • Wire Size: 14 AWG to 3/0 AWG (aluminium/copper terminal)
  • Certification: UL, CSA, NOM
  • Terminal Connection: Line/Load Lug
  • Phase Connection: Not Applicable
  • Family: Powerpact
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901577874
  • GTIN: 00785901577874
