Square D HDL26040 - 40A 2-Pole Thermal Magnetic Breaker (600V, 18kA AIC)
Square D HDL26040 - 40A 2-Pole Thermal Magnetic Breaker (600V, 18kA AIC)

Square D HDL26040 - 40A 2-Pole Thermal Magnetic Breaker (600V, 18kA AIC)

Square D
Price
Save $336.25
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Square D HDL26040 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial power distribution systems. It features a 40A current rating and a 600V voltage rating, housed within a compact 150A/HD frame measuring 163 mm H x 104 mm W x 86 mm D and weighing 3.049 lb. This thermal magnetic breaker is constructed for feed-thru connection with line/load lugs, compliant with UL, CSA, NEMA, NOM, and IEC 60947-2 standards, making it suitable for a wide range of commercial and industrial panelboard applications.

Key Features & Specifications
  • Type: Standard thermal magnetic molded case circuit breaker with Long-Time and Instantaneous (LI) trip functions
  • Voltage Rating: 600V AC
  • Current Rating: 40A
  • Frame Size: 150A/HD
  • Poles: 2
  • AIC Rating: 18kA at 480V AC
  • Connection: Feed-Thru with Line/Load Lug terminals
  • Wire Size Range: 14 AWG to 3/0 AWG (aluminium/copper)
  • Phase: 1
  • Operating Temperature: -2°C to 70°C (28°F to 158°F)
  • Standards & Certification: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Dimensions: 163 mm H x 104 mm W x 86 mm D (6.4 in x 4.09 in x 3.4 in)
  • Weight: 3.049 lb
  • Family: Powerpact
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901706533
  • GTIN: 00785901706533
