Square D H368N is a heavy-duty fusible safety switch designed for isolating and protecting high-current three-phase industrial circuits. It provides reliable circuit protection with a 1200A current rating and a 600V AC/DC voltage rating, housed within a robust NEMA 1 enclosure measuring 1755.9 mm H x 930.15 mm W x 450.85 mm D and weighing 362 lb. The switch is UL Listed and features a 200kA interrupting capacity at 600V, ensuring compliance with stringent safety standards for demanding applications such as industrial power distribution, large motor control centers, and main service disconnects.

Key Features & Specifications
  • Type: Fusible Safety Disconnect Switch
  • Voltage Rating: 600V AC/DC
  • Current Rating: 1200A
  • Configuration: Single, 3-Pole
  • Phase: 3
  • AIC Rating: 200kA @ 600V
  • Fuse Class: R, L
  • Wire Size: 4 AWG
  • NEMA Rating: NEMA 1
  • Certification: UL Listed
  • Dimensions: 1755.9 mm H x 930.15 mm W x 450.85 mm D (69.13 in x 36.62 in x 17.75 in)
  • Weight: 362 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 78590144246
  • GTIN: 00785901442462
