Mersen GSC8 - GSC Time-Delay Fuse 8A 250V (10kA AIC)

Mersen GSC8 is a low-voltage time-delay fuse designed for circuit protection in industrial applications. It features a 250V AC rating with an 8A current capacity and 10kA interrupting rating at 125V, housed in a compact 0.79-inch diameter ferrule-connected barrel construction. The UL Listed and CSA Certified fuse meets stringent safety standards with its current-limiting design. Typical applications include motor control centers, transformers, and power distribution equipment requiring delayed response to temporary overloads.

Key Features & Specifications

• Type: GSC class time-delay fuse with current-limiting protection
• Voltage Rating: 250V AC
• Current Rating: 8A
• Dimensions: 0.79" diameter x 1.5" length (standard GSC size)
• Connection: Ferrule (blade) terminals
• Barrels: Single barrel construction
• AIC Rating: 10,000A @ 125V
• Certification: UL Listed, CSA Certified
• Operating Characteristics: Time-delay (slow-blow) protection
• Standards: Meets UL 248-10 and CSA C22.2 No. 248.10

Product Identification

• UPC: 078200176586
• GTIN: 00782001765866
