ACP Electrical Fittings GLNP0751000 is a non-fusible, heavy-duty safety switch designed for reliable circuit isolation and protection in industrial power distribution systems. This switch is rated for 600V AC maximum and 100A continuous current, providing robust performance for demanding electrical environments. Constructed with a NEMA 3R rainproof enclosure of galvanized steel, it measures approximately 10.5 inches in height, 6.5 inches in width, and 4.5 inches in depth, weighing 5.19 lb. It complies with UL 98 and CSA C22.2 No. 4 standards, ensuring safe operation and adherence to North American electrical codes. Typical applications include motor disconnects, lighting panel feeders, and machinery isolation in manufacturing plants, commercial buildings, and utility substations.

Key Features & Specifications
  • Type: Non-fusible, heavy-duty safety switch with quick-make/quick-break operation
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Dimensions: 10.5 x 6.5 x 4.5 inches
  • Standards: UL 98, CSA C22.2 No. 4
  • Applications: Motor disconnects, lighting panel feeders, machinery isolation
  • Switch Type: Non-fusible
  • Configuration: 2-pole, single-throw
  • Coil Voltage Maximum: N/A
  • Temp Rating: -20°C to 60°C
  • Shipping Dimensions: 12 x 8 x 6 inches
  • Phase: Single-phase
  • Voltage: 600V AC
  • Amperage: 100A
  • AIC rating: 10kA at 600V AC
  • Connection: Screw terminals
  • Poles: 2
  • Protection: Overcurrent protection via external fuses
  • Functions: Circuit isolation, disconnect
  • Frame Size: NEMA 3R
  • Trip Type: N/A (non-fusible)
  • Panel Type: Surface mount
  • Breaker Type: N/A
  • Control Voltage Minimum: N/A
  • Control Voltage Maximum: N/A
  • MCM Size: N/A
  • Metal Type: Galvanized steel
  • Panel Style: Rainproof
  • Bus Type: Copper
  • Fuse Class: N/A
  • Insulation Temperature: 105°C
  • Inductance: N/A
  • Impedance: N/A
  • Barrels: N/A
  • Class Rating: N/A
  • Diameter: N/A
  • Velocity: N/A
  • Clip Center: N/A
  • Clas: N/A
  • Mounting: Surface
  • Hz: 50/60
  • Coil Material: N/A
  • Horse Power: 50 HP at 600V
  • Aux Contacts: 1 N.O.
  • CPT: N/A
  • Full Load Amps: 100A
  • Dist Voltage: N/A
  • Bucket Size: N/A
  • Bucket Style: N/A
  • Bucket Type: N/A
  • Full Load Amp Maximum: 100A
  • Full Load Amp Minimum: 0A
  • Enclosure: NEMA 3R
  • Relay Style: N/A
  • Coil Voltage Minimum: N/A
  • Wire: Copper/Aluminum
  • Amperage Maximum: 100A
  • Amperage Minimum: 0A
  • Nema Rating: 3R
  • Switch Style: Heavy-duty
  • Wire Size: #14 to #2 AWG
  • Certification: UL, CSA
  • Circuit Breaker Mounting Style: N/A
  • Terminal Connection: Screw
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Single-phase
  • Standards: UL 98, CSA C22.2 No. 4
  • Compatible Frames: N/A
  • Installation Type: Surface
  • Item QTY: 1
  • Nema Starter Size: N/A
  • Breaker Frame: N/A
  • Current Rating: 100A
  • Reverse Standoff Voltage: N/A
  • Watts: N/A
  • Peak Pulse Current: N/A
  • Breakdown Voltage (MIN VBR@IT ) (V): N/A
  • Breakdown Voltage (VBR@IT) (V): N/A
  • Polarity: N/A
  • Operating Temperature Maximum Celsius: 60°C
  • Max Clamp Voltage: N/A
  • On-State Current: N/A
