Cutler-Hammer GHB3035 - 35A 3-Pole Circuit Breaker (480V, 14kA)
Cutler-Hammer GHB3035 - 35A 3-Pole Circuit Breaker (480V, 14kA)
Cutler-Hammer GHB3035 - 35A 3-Pole Circuit Breaker (480V, 14kA)
Cutler-Hammer GHB3035 - 35A 3-Pole Circuit Breaker (480V, 14kA)

Cutler-Hammer GHB3035 - 35A 3-Pole Circuit Breaker (480V, 14kA)

Cutler Hammer
Price
Save $569.10
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Cutler-Hammer GHB3035 is a three-pole, 35-amp molded case circuit breaker designed to provide reliable thermal-magnetic protection for three-phase electrical systems. It is rated for 480V AC applications and features a 14kA interrupting capacity at this voltage, housed within a compact, bolt-on frame measuring 2.63" D x 4" H x 3" W and weighing 1.75 lb. This UL 538-listed and CSA-certified breaker utilizes a screw clamp terminal connection compatible with 10 to 1/0 AWG wire and is engineered for operation in ambient temperatures from -2°C to 70°C (28°F to 158°F). It is typically applied in Eaton Powerline panelboards for the protection of feeders and branch circuits in commercial and industrial facilities.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 480V AC
  • Current Rating: 35A
  • Frame Size: 100/GHB
  • Poles: 3
  • AIC Rating: 14kA @ 480V AC
  • Phase: 3
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Connection: Bolt-On
  • Terminal Connection: Screw Clamp
  • Wire Size: 10 to 1/0 AWG
  • Dimensions: 2.63 in (Depth) x 4 in (Height) x 3 in (Width)
  • Weight: 1.75 lb
  • Temp Rating: -2°C to 70°C (28°F to 158°F)
  • Standards: UL 538
  • Certification: UL Listed, CSA Certified
  • Panel Type: Eaton Powerline Panelboards
  • Breaker Type: Standard
  • Protection: Thermal Magnetic
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679172605
  • GTIN: 00786679172605
