Cutler Hammer GHB2080 - 80A Molded Case Breaker (480V, 14kA AIC)
Cutler Hammer GHB2080 - 80A Molded Case Breaker (480V, 14kA AIC)
Cutler Hammer GHB2080 - 80A Molded Case Breaker (480V, 14kA AIC)
Cutler Hammer GHB2080 - 80A Molded Case Breaker (480V, 14kA AIC)

Cutler Hammer GHB2080 - 80A Molded Case Breaker (480V, 14kA AIC)

Cutler Hammer
Price
Save $969.30
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer GHB2080 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial power distribution systems. It features an 80A current rating and a 480V AC voltage rating, housed within a compact 100/GHB frame measuring 2.63 in x 4 in x 2 in (L/D x H x W) and weighing 1.3 lb. This thermal magnetic breaker is UL 518 listed and CSA certified, ensuring compliance with industry safety standards for use in Eaton Powerline panelboards and similar single-phase applications.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Standard Type, Thermal Magnetic Protection with Long-Time and Instantaneous (LI) Trip Functions
  • Voltage Rating: 480V AC
  • Current Rating: 80A
  • Frame Size: 100/GHB
  • Poles: 2
  • AIC Rating: 14kA @ 480V
  • Connection: Bolt-On with Screw Clamp Terminal
  • Wire Size: 10 to 1/0 AWG (MCM)
  • Phase: 1
  • Dimensions: 2.63 in x 4 in x 2 in (Length/Depth x Height x Width)
  • Weight: 1.3 lb
  • Temp Rating: -2 to 70 °C (28 to 158 °F)
  • Standards & Certification: UL 518, CSA Certified, UL Listed
  • Panel Type: Compatible with Eaton Powerline Panelboards
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679111178
  • GTIN: 00786679111178
