Cutler Hammer GHB2015 - Molded Case Circuit Breaker 15A 480V 2-Pole
Cutler Hammer GHB2015 - Molded Case Circuit Breaker 15A 480V 2-Pole
Cutler Hammer GHB2015 - Molded Case Circuit Breaker 15A 480V 2-Pole
Cutler Hammer GHB2015 - Molded Case Circuit Breaker 15A 480V 2-Pole

Cutler Hammer GHB2015 - Molded Case Circuit Breaker 15A 480V 2-Pole

Cutler Hammer
Price
Save $399.06
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer GHB2015 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial and commercial electrical systems. It features a 15A current rating and a 480V AC voltage rating, housed within a compact 100/GHB frame measuring 2.63 in x 4 in x 2 in (L x H x W) and weighing 1 lb. This thermal magnetic breaker is CSA Certified and UL Listed to standard 506, ensuring compliance with North American safety requirements. Its 14kA interrupting rating at 480V and bolt-on, two-pole configuration make it suitable for installation in Eaton Powerline panelboards for protecting single-phase branch circuits.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection with Long-Time and Instantaneous (LI) Trip Functions
  • Voltage Rating: 480V AC
  • Current Rating: 15A
  • Frame Size: 100/GHB
  • Poles: 2
  • Connection: Bolt-On with Screw Clamp Terminals
  • AIC Rating: 14kA @ 480V AC
  • Phase: 1
  • Standards & Certification: UL 506, CSA Certified, UL Listed
  • Dimensions: 2.63 in (Depth) x 4 in (Height) x 2 in (Width)
  • Weight: 1 lb
  • Temp Rating: -2°C to 70°C (28°F to 158°F)
  • Wire Size Range (MCM): 10 AWG (Min) to 1/0 AWG (Max)
  • Panel Type: Compatible with Eaton Powerline Panelboards
  • Breaker Type: Standard
  • Protection: Thermal Magnetic
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679911198
  • GTIN: 00786679911198
