Siemens GF323NR - Fusible Safety Switch, 100A 3P (240V AC, 100kA AIC)

Siemens
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Siemens GF323NR is a fusible safety switch designed for providing visible disconnect and overcurrent protection in three-phase industrial power distribution systems. It is rated for 240V AC operation with a 100A current rating and features a 100kA interrupting capacity at 240V for reliable short-circuit protection. The switch is constructed with a NEMA 3R-rated enclosure for outdoor use, measures 25.591 x 13.78 x 7.48 inches, and weighs 21.451 lb, operating within a temperature range of -25°C to 70°C. It is UL listed and designed for compatibility with MGP frames, ensuring compliance with industry safety standards for applications such as motor control centers and main service disconnects.

Key Features & Specifications
  • Type: Fusible safety disconnect switch, VBII Series
  • Voltage Rating: 240V AC
  • Current Rating: 100A
  • Dimensions: 25.591 x 13.78 x 7.48 inch
  • Standards: UL listed, NEMA 3R enclosure rating
  • Applications: Industrial power distribution, motor control centers, main service disconnects
  • Switch Type: Fusible
  • Configuration: Single
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 3
  • AIC rating: 100kA @ 240V
  • Poles: 3
  • Protection: Overcurrent and short-circuit (via Class R fuses)
  • Fuse Class: R
  • Compatible Frames: MGP
  • Weight: 21.451 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643149311
  • GTIN: 00783643149311
