Siemens GF322NRA - Fusible Safety Switch 60A 3P (100kA AIC)

Siemens
Price
Save $840.10
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens GF322NRA is a fusible safety switch designed for providing reliable circuit isolation and short-circuit protection in industrial applications. It is rated for 240V AC operation with a 60A current rating, housed in a compact, durable enclosure measuring 6.693 x 3.937 x 9.843 inches and weighing 4.012 lb. The switch is UL listed, carries a NEMA 3R rating for outdoor use, and is designed to withstand an ambient temperature range of -25°C to 70°C. Its robust construction, featuring a 3-pole, single-configuration design with a 100kA interrupting capacity at 240V, makes it suitable for integration into MEP-compatible frames within motor control centers and industrial power distribution systems.

Key Features & Specifications
  • Type: Fusible Safety Disconnect Switch, VBII Series
  • Voltage Rating: 240V AC
  • Current Rating: 60A
  • Dimensions: 6.693 x 3.937 x 9.843 inch (170 x 100 x 250 mm)
  • Standards: UL Listed, NEMA 3R Enclosure Rating
  • Applications: Industrial power distribution, motor control centers (MCCs), circuit isolation and protection
  • Switch Type: Fusible Disconnect
  • Configuration: Single
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Shipping Dimensions: 6.693 x 3.937 x 9.843 inch
  • Phase: Three-Phase
  • Voltage: 240V AC
  • Amperage: 60A
  • AIC rating: 100kA @ 240V
  • Poles: 3
  • Protection: Short-circuit via fuses
  • Functions: Isolation, Safety Disconnect
  • Nema Rating: 3R
  • Certification: UL listed
  • Compatible Frames: MEP
  • Country of Origin: Mexico
  • Weight: 4.012 lb


Product Identification
  • UPC: 804766753466
  • GTIN: 00804766753466
