Siemens GF322N - Fusible Safety Switch, 60A 3P 240V (100kA AIC)
Siemens GF322N - Fusible Safety Switch, 60A 3P 240V (100kA AIC)
SIemens GF322N Disconnect Switch (Fusible) - Essential Electric Supply
SIemens GF322N Disconnect Switch (Fusible) - Essential Electric Supply
Siemens GF322N - Fusible Safety Switch, 60A 3P 240V (100kA AIC)
Siemens GF322N - Fusible Safety Switch, 60A 3P 240V (100kA AIC)

Siemens GF322N - Fusible Safety Switch, 60A 3P 240V (100kA AIC)

Siemens
Price
Save $424.23
/
Title
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Siemens GF322N is a fusible safety switch designed for providing reliable circuit protection and isolation in industrial power distribution. It is rated for 240V AC, 60A, 3-phase operation and features a 100kA interrupting capacity at 240V for robust short-circuit protection. The unit is constructed with a NEMA 1 enclosure measuring 18.11 x 10.63 x 7.48 inches (460 x 270 x 190 mm) and a weight of 12.236 lb, and it operates reliably within a temperature range of -25°C to 70°C (-13°F to 158°F). This UL-listed disconnect switch complies with industry standards and is compatible with MEP frames, making it suitable for use in motor control centers, industrial panels, and other three-phase applications requiring a Class R fusible disconnect.

Key Features & Specifications
  • Type: Fusible safety disconnect switch, VBII Series
  • Voltage Rating: 240V AC
  • Current Rating: 60A
  • Configuration: Single, 3-pole
  • AIC Rating: 100kA @ 240V
  • Fuse Class: R
  • Dimensions: 18.11 x 10.63 x 7.48 in (460 x 270 x 190 mm)
  • Weight: 12.236 lb
  • Phase: 3
  • NEMA Rating: NEMA 1
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Certification: UL Listed
  • Compatible Frames: MEP
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643148130
  • GTIN: 00785901766155
