Siemens GF224N - Fusible Safety Disconnect Switch 200A @ 240V AC (100kA AIC, NEMA 1)

Siemens GF224N is a fusible safety disconnect switch designed for circuit protection and isolation in industrial applications. This 200A rated switch operates at 240V AC with a 100kA interrupting capacity, providing robust protection against short circuits. The unit features a compact 16.7 x 31.1 inch NEMA 1 enclosure constructed for durable performance in industrial environments. UL listed certification ensures compliance with industry safety standards, while compatibility with MEP frames facilitates integration into existing electrical systems. Typical applications include motor control centers, industrial machinery, and power distribution systems requiring reliable circuit isolation.

Key Features & Specifications

• Type: Fusible safety disconnect switch, VBII Series
• Voltage Rating: 240V AC
• Current Rating: 200A
• Dimensions: 16.7 in x 31.1 in
• Standards: UL listed
• Applications: Industrial power distribution, motor control centers
• Switch Type: GF
• Configuration: Single
• Poles: 2
• Protection: Circuit isolation and short circuit protection
• Frame Size: Compatible with MEP frames
• AIC rating: 100kA@240V
• Switch Style: Fusible
• Nema Rating: 1
• Phase: 1
• Fuse Class: R
• Enclosure: NEMA 1
• Country of Origin: Mexico
• Weight: 20 lb

Product Identification

• UPC: 783643148086
• GTIN: 00783643148086
