Siemens GF221NR - Fusible Disconnect 30A 240V (NEMA 3R)
Siemens GF221NR - Fusible Disconnect 30A 240V (NEMA 3R)
Siemens GF221NR - Fusible Disconnect 30A 240V (NEMA 3R)
SIemens GF221NR Disconnect Switch (Fusible) - Essential Electric Supply
SIemens GF221NR Disconnect Switch (Fusible) - Essential Electric Supply
Siemens GF221NR - Fusible Disconnect 30A 240V (NEMA 3R)
Siemens GF221NR - Fusible Disconnect 30A 240V (NEMA 3R)
Siemens GF221NR - Fusible Disconnect 30A 240V (NEMA 3R)

Siemens GF221NR - Fusible Disconnect 30A 240V (NEMA 3R)

Siemens
Price
Save $254.45
/
Title
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
Siemens GF221NR is a fusible safety switch designed for providing reliable circuit isolation and overcurrent protection in industrial and commercial applications. It is rated for 240V AC operation with a 30A current capacity and features a 100kA interrupting rating at 240V for robust short-circuit protection. The switch is constructed within a NEMA 3R-rated enclosure measuring 18.11 x 12.598 x 9.055 inches (460 x 320 x 230 mm) and weighing 3.902 lb, ensuring durability for outdoor use where exposed to rain and sleet. It is UL listed and operates reliably across a wide temperature range from -25°C to 70°C (-13°F to 158°F). This single-phase, 2-pole disconnect is compatible with MEP frames and utilizes Class R fuses, making it suitable for service entrance, motor control centers, and HVAC equipment.

Key Features & Specifications
  • Type: Fusible safety disconnect switch, VBII Series
  • Voltage Rating: 240V AC
  • Current Rating: 30A
  • Dimensions: 18.11 x 12.598 x 9.055 in (460 x 320 x 230 mm)
  • Weight: 3.902 lb
  • Standards: UL listed, NEMA 3R enclosure rating
  • Applications: Service entrance, motor control, HVAC, industrial power distribution
  • Switch Type: Fusible Disconnect
  • Configuration: Single
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 1
  • AIC rating: 100kA @ 240V
  • Connection: Screw terminal
  • Poles: 2
  • Protection: Overcurrent via Class R fuses
  • Frame Size: Compatible with MEP frames
  • Fuse Class: R
  • Enclosure: NEMA 3R
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643335189
  • GTIN: 00785901627890
