Siemens FXD63B080 - Molded Case Circuit Breaker 80A 600V 3P
Siemens FXD63B080 - Molded Case Circuit Breaker 80A 600V 3P

Siemens FXD63B080 - Molded Case Circuit Breaker 80A 600V 3P

Siemens
Price
Save $6,653.32
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens FXD63B080 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power distribution systems. It features a thermal-magnetic trip unit with long-time and instantaneous functions, rated for 80A continuous current and 600V AC maximum voltage. The breaker is constructed within a compact FD frame measuring 150 x 250 x 170 mm (W x H x D) and weighing 8.4 lb, utilizing a standard bolt-on connection for secure installation. It complies with UL, CSA, and IEC standards and is certified for an interrupting capacity of 35kA at 480V AC. Typical applications include integration into panelboards such as S4, P4, SPP, F1, FC1, FCII, CDP-5, CDP-6, SB1-3, S5, P5, SPP/FPP, and F2 types, operating effectively within an ambient temperature range of -25°C to 70°C.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Standard Trip, Bolt-On Connection
  • Voltage Rating: 600V AC
  • Current Rating: 80A
  • Dimensions: 150mm W x 250mm H x 170mm D (5.906" x 9.843" x 6.693")
  • Standards: UL, CSA, IEC
  • Applications: Industrial Power Distribution, Panelboards (S4, P4, SPP, F1, FC1, FCII, CDP-5, CDP-6, SB1-3, S5, P5, SPP/FPP, F2)
  • Frame Size: FD Frame
  • Trip Type: Thermal-Magnetic
  • Phase: 3
  • Poles: 3
  • AIC Rating: 35kA @ 480V AC
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Connection: Bolt-On
  • Protection: Overcurrent, Short-Circuit
  • Functions: Long Time Trip, Instantaneous Trip
  • Breaker Type: Standard
  • Panel Type: S4, P4, SPP, F1, FC1, FCII, CDP-5, CDP-6, SB1-3, S5, P5, SPP/FPP, F2
  • Weight: 8.4 lb
  • Family: Sentron Series
  • Country of Origin: Mexico
  • Additional Info: Lugs are not included and must be purchased separately


Product Identification
  • UPC: 783643211209
  • GTIN: 00783643211209
