Siemens FXD63A150 - Molded Case Circuit Breaker 150A 600V
Siemens FXD63A150 - Molded Case Circuit Breaker 150A 600V

Siemens FXD63A150 - Molded Case Circuit Breaker 150A 600V

Siemens
Price
Save $11,995.69
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens FXD63A150 is a molded case circuit breaker designed for providing instantaneous magnetic-only protection in three-phase industrial power distribution systems. It features a 150A current rating and a 600V AC voltage rating, housed within a compact FD frame with bolt-on connections measuring 150mm wide by 250mm high by 170mm deep (5.906" x 9.843" x 6.693") and weighing 8.598 lb. The breaker is certified to UL, CSA, and IEC standards and operates reliably within a temperature range of -25°C to 70°C (-13°F to 158°F). Its 35kA interrupting capacity at 480V AC makes it suitable for protecting feeders and branch circuits in commercial and industrial panelboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Magnetic-Only Protection, Instantaneous Trip
  • Voltage Rating: 600V AC
  • Current Rating: 150A
  • Dimensions: 150mm W x 250mm H x 170mm D (5.906" x 9.843" x 6.693")
  • Standards: UL, CSA, IEC
  • Applications: Industrial Feeder and Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Three-Pole
  • Phase: 3
  • AIC Rating: 35kA @ 480V AC
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Magnetic Only
  • Functions: Instantaneous
  • Frame Size: FD Frame
  • Trip Type: Magnetic
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Certification: UL, CSA, IEC
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643212275
  • GTIN: 00783643212275
