Bussmann FWX-90A - Low Voltage Fuse 90A (200kA AIC @ 250V)

Bussmann FWX-90A is a low-voltage current-limiting fuse designed for providing high-level short-circuit protection in industrial electrical systems. It features a 90A current rating and a 250V voltage rating, engineered to safely interrupt fault currents up to 200kA. The fuse is constructed with a robust stud connection type and a single-barrel design, measuring 3.11 inches in length and height, 1.23 inches in width, and featuring a 1.22-inch diameter with a total weight of 1.3 lb. It complies with industry standards for high-interrupting capacity fuses and is typically applied in motor control centers, industrial control panels, and feeder circuits where reliable protection against high fault currents is critical.

Key Features & Specifications

• Type: FWX Series, Low Voltage Fuse, Current-Limiting, Stud Connection, Single Barrel
• Voltage Rating: 250V AC
• Current Rating: 90A
• Dimensions: 3.11in (L) x 3.11in (H) x 1.23in (W)
• Diameter: 1.22in
• Weight: 1.3 lb
• Standards: Industry standards for high-interrupting capacity fuses
• Applications: Motor Control Centers, Industrial Control Panels, Feeder Circuits
• Connection: Stud
• Barrels: 1
• AIC rating: 200kA @ 250V
• Family: FWX Series

Product Identification

• UPC: 051712150620
• GTIN: 00051712150620
