Bussmann FWP-500A - Low Voltage Fuse 500A (200kA@700V Interrupting Capacity)

Bussmann FWP-500A is a low-voltage fuse designed for high-current circuit protection in industrial applications. It features a 700V AC/DC voltage rating and a 500A current rating, with a robust stud connection and single-barrel construction for secure installation. The fuse measures 7-3/32 inches in length with a 2.5-inch diameter and 2 lb weight, built to withstand demanding environments. Certified to CE, CSA, and UL standards, it offers a 200kA interrupting capacity at 700V for reliable fault protection. Typical applications include power distribution systems, motor control centers, and heavy industrial equipment requiring high interrupting ratings.

Key Features & Specifications

• Type: FWP series low-voltage fuse with stud connection
• Voltage Rating: 700V AC/DC
• Current Rating: 500A
• Dimensions: 7-3/32 in length, 2.5 in diameter
• Weight: 2 lb
• Standards: CE, CSA Certified, UL Recognized
• Applications: Industrial power distribution, motor protection
• AIC Rating: 200kA@700V
• Connection: Stud
• Barrels: 1
• Country of Origin: Mexico

Product Identification

• UPC: 051712150453
• GTIN: 00051712150453
