Bussmann FWA-800A - FWA Series Fuse 800A 150V (200kA AIC)

Price
Regular price $282.05
Regular price $727.99 Sale price $282.05
Save $445.94
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Bussmann FWA-800A is a low-voltage current-limiting fuse designed for high-amperage circuit protection in industrial power distribution systems. It features a 150V AC/DC voltage rating and a precise 800A current rating, engineered to safely interrupt fault currents up to 200kA at its rated voltage. The fuse is constructed with a single-barrel design and stud-type connections, housed in a compact, durable body measuring 25.4 mm x 25.4 mm x 89 mm and weighing 0.4393 lb. It complies with UL recognition and CE marking standards, ensuring reliability for demanding applications such as protecting bus bars, switches, and industrial control equipment.

Key Features & Specifications
  • Type: FWA Series, low-voltage current-limiting fuse with stud connection
  • Voltage Rating: 150V AC/DC
  • Current Rating: 800A
  • Dimensions: 25.4 mm x 25.4 mm x 89 mm (Length/Depth x Height x Width)
  • Standards: UL Recognized, CE Marked
  • Applications: Industrial power distribution, bus bar protection, switchgear
  • AIC rating: 200kA @ 150V
  • Connection: Stud
  • Barrels: 1
  • Diameter: 1.5 in
  • Weight: 0.4393 lb


Product Identification
  • UPC: 051712795456
  • GTIN: 00051712795456
