Bussmann FNA-8/10 - Midget Fast-Acting Fuse 8A 250V (10kA AIC Rating)

The Bussmann FNA-8/10 is a midget fast-acting fuse designed for overcurrent protection in low voltage electrical circuits. It features a 250V AC voltage rating with an 8A current rating and 10kA interrupting capacity at 250V for reliable circuit protection. The fuse measures 1-1/2 inches in length with a 0.41-inch diameter and single-barrel construction, weighing 1.1 lb for compact installation. It complies with CE, CSA Class 1422-01, and UL-248-12 Guide JDYX standards, ensuring industry-recognized safety and performance. This fuse is commonly used in industrial control circuits, instrumentation, and electronic equipment requiring precise overcurrent protection.

Key Features & Specifications

• Type: FNA Series fast-acting midget fuse with single-barrel construction
• Voltage Rating: 250V AC
• Current Rating: 8A
• Dimensions: 1-1/2 inch length x 0.41 inch diameter
• Standards: CE, CSA Class 1422-01, UL-248-12 Guide JDYX
• Applications: Industrial control circuits, instrumentation, electronic equipment protection
• AIC rating: 10kA@250V
• Class Rating: Midget
• Barrels: 1
• Weight: 1.1 lb
• Family: FNA Series
• Country of Origin: Mexico

Product Identification

• UPC: 05171271342
• GTIN: 00051712713429
