Cutler Hammer FDC3125 - Molded Case Circuit Breaker 125A 600V 3P
Cutler Hammer FDC3125 - Molded Case Circuit Breaker 125A 600V 3P
Cutler Hammer FDC3125 - Molded Case Circuit Breaker 125A 600V 3P
Cutler Hammer FDC3125 - Molded Case Circuit Breaker 125A 600V 3P
Cutler Hammer FDC3125 - Molded Case Circuit Breaker 125A 600V 3P
Cutler Hammer FDC3125 - Molded Case Circuit Breaker 125A 600V 3P

Cutler Hammer FDC3125 - Molded Case Circuit Breaker 125A 600V 3P

Cutler Hammer
Price
Save $8,790.22
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer FDC3125 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power distribution systems. It features a 125A continuous current rating and a 600V AC voltage rating, housed within a compact F-frame measuring 3.38 in (D) x 4.13 in (H) x 4.13 in (W) and weighing 4.5 lb. This UL Listed device utilizes a thermal-magnetic trip unit with long-time and instantaneous (LI) protection functions and offers a high interrupting capacity of 100kA at 480V AC. Its bolt-on connection design and compatibility with wire sizes from AWG 14 to 3/0 for aluminum or copper conductors make it suitable for panelboards, switchboards, and industrial control panels.

Key Features & Specifications
  • Type: FDC Series C, Molded Case, Thermal-Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 125A
  • Dimensions: 3.38 in (Depth) x 4.13 in (Height) x 4.13 in (Width)
  • Weight: 4.5 lb
  • Standards: UL Listed
  • Applications: Industrial Power Distribution, Panelboards, Switchboards
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Phase: 3
  • Amperage: 125A
  • AIC Rating: 100kA @ 480V AC
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI)
  • Frame Size: F Frame
  • Wire Size: AWG 14 to AWG 3/0 (Aluminum/Copper)
  • Certification: UL Listed
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679451649
  • GTIN: 00786679451649
