Westinghouse FDC3015 - Molded Case Circuit Breaker 15A 600V 3P
Westinghouse FDC3015 - Molded Case Circuit Breaker 15A 600V 3P
Westinghouse FDC3015 - Molded Case Circuit Breaker 15A 600V 3P
Westinghouse FDC3015 - Molded Case Circuit Breaker 15A 600V 3P
Westinghouse FDC3015 - Molded Case Circuit Breaker 15A 600V 3P
Westinghouse FDC3015 - Molded Case Circuit Breaker 15A 600V 3P

Westinghouse FDC3015 - Molded Case Circuit Breaker 15A 600V 3P

Cutler Hammer
Price
Save $2,941.44
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Westinghouse FDC3015 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial electrical systems. It features a 15A current rating and a 600V AC voltage rating for robust circuit protection. The breaker is constructed with a compact F-frame size measuring 3.38 in (depth) x 6 in (height) x 4.13 in (width) and a bolt-on connection, utilizing a thermal-magnetic trip unit for combined long-time and instantaneous trip functions. This Series C family device is UL Listed and offers an interrupting capacity of 100kA at 480V, ensuring compliance with critical safety standards. It is engineered for a wide operating temperature range of -25 to 70 °C and is typically applied in industrial panelboards, switchboards, and motor control centers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, FDC Type
  • Voltage Rating: 600V AC
  • Current Rating: 15A
  • Dimensions: 3.38 in (D) x 6 in (H) x 4.13 in (W)
  • Standards: UL Listed
  • Applications: Industrial Panelboards, Switchboards, Motor Control Centers
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Phase: 3
  • AIC Rating: 100kA @ 480V
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Trip Type: Thermal-Magnetic
  • Breaker Type: Molded Case
  • Insulation Temperature: Rated for -25 to 70 °C operation
  • Mounting: Designed for panel mounting
  • Certification: UL Listed
  • Circuit Breaker Mounting Style: Bolt-On
  • Terminal Connection: Bolt-On
  • Phase Connection: 3-Phase
  • Standards: UL
  • Current Rating: 15A
  • Operating Temperature Maximum Celsius: 70 °C
  • Weight: 4.3 lb


Product Identification
  • UPC: 786679451427
  • GTIN: 00786679451427
