Cutler Hammer FDB3150 - Molded Case Circuit Breaker 150A 600V 3P
Cutler Hammer FDB3150 - Molded Case Circuit Breaker 150A 600V 3P
Cutler Hammer FDB3150 - Molded Case Circuit Breaker 150A 600V 3P
Cutler Hammer FDB3150 - Molded Case Circuit Breaker 150A 600V 3P
Cutler Hammer FDB3150 - Molded Case Circuit Breaker 150A 600V 3P
Cutler Hammer FDB3150 - Molded Case Circuit Breaker 150A 600V 3P

Cutler Hammer FDB3150 - Molded Case Circuit Breaker 150A 600V 3P

Cutler Hammer
Price
Save $2,560.22
/
Condition
  • Low stock - 4 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer FDB3150 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial power distribution systems. It features a 150A current rating and a 600V voltage rating, housed within a compact F-frame measuring 3.38 in x 4.13 in x 4.13 in with a bolt-on connection. This UL Listed breaker utilizes a thermal-magnetic trip mechanism for both long-time and instantaneous protection, is rated for an interrupting capacity of 14kA at 480V, and operates within a temperature range of -25 to 70 °C (-13 to 158 °F). It is engineered for integration into panelboards and switchboards to safeguard motors, feeders, and other critical equipment.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, FDB Series C
  • Voltage Rating: 600V AC
  • Current Rating: 150A
  • Dimensions: 3.38 in (D) x 4.13 in (H) x 4.13 in (W)
  • Standards: UL Listed
  • Applications: Industrial power distribution, motor protection, feeder protection
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 3
  • AIC Rating: 14kA @ 480V
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal-Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Trip Type: Thermal-Magnetic
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Weight: 4.5 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679306079
  • GTIN: 00786679306079
