Eaton FD3070 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial power distribution systems. It features a 70A current rating and a 600V voltage rating, housed within a compact 225A frame with dimensions of 3.38" D x 6" H x 4.13" W and a weight of 4.5 lb. The breaker utilizes a thermal-magnetic trip mechanism for long-time and instantaneous (LI) protection, is CSA, UL, and IEC certified, and offers a 35kA interrupting capacity at 480V. Its bolt-on connection with load-side lugs, compatibility with wire sizes from 14 AWG to 1/0 AWG, and an operating temperature range from -4°F to 158°F make it suitable for installation in motor control centers, switchboards, and enclosed controls from major manufacturers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Standard, Thermal Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 70A
  • Frame Size: 225A/F
  • Poles: 3
  • AIC Rating: 35kA @ 480V
  • Connection: Bolt-On, Load Side Lug Terminals
  • Phase Connection: 3-Phase (ABC)
  • Functions: LI (Long-Time and Instantaneous)
  • Dimensions: 3.38 in (D) x 6 in (H) x 4.13 in (W)
  • Weight: 4.5 lb
  • Wire Size Range: 14 AWG to 1/0 AWG
  • Temp Rating: -4°F to 158°F Operating Range
  • Standards/Certification: CSA Certified, IEC Rated, UL Listed
  • Panel Type: Compatible with Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679305720
  • GTIN: 00786679305720
