Westinghouse FD1060 - Molded Case Circuit Breaker 60A 277V 1P
Westinghouse FD1060 - Molded Case Circuit Breaker 60A 277V 1P
Westinghouse FD1060 - Molded Case Circuit Breaker 60A 277V 1P
Westinghouse FD1060 - Molded Case Circuit Breaker 60A 277V 1P
Westinghouse FD1060 - Molded Case Circuit Breaker 60A 277V 1P
Westinghouse FD1060 - Molded Case Circuit Breaker 60A 277V 1P

Westinghouse FD1060 - Molded Case Circuit Breaker 60A 277V 1P

Cutler Hammer
Price
Save $823.63
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Westinghouse FD1060 is a molded case circuit breaker designed to provide reliable overcurrent protection for industrial and commercial electrical systems. It features a 60A current rating and a 277V AC voltage rating, suitable for single-phase applications. The breaker is constructed with a compact F-frame size, measuring 3.38 in (L) x 6 in (H) x 1.38 in (W) and weighing 4.5 lb, and utilizes a bolt-on connection for secure installation. It is UL Listed and offers thermal-magnetic protection with both long-time and instantaneous trip functions, ensuring compliance with industry safety standards. Typical applications include protecting feeders, branch circuits, and equipment within panelboards and switchboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 277V AC
  • Current Rating: 60A
  • Dimensions: 3.38 in x 6 in x 1.38 in (Length x Height x Width)
  • Standards: UL Listed
  • Applications: Industrial/Commercial Panelboards, Feeder & Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Single Pole
  • Phase: 1
  • Amperage: 60A
  • AIC Rating: 35kA @ 277V
  • Connection: Bolt-On
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Weight: 4.5 lb
  • Certification: UL Listed
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679312162
  • GTIN: 00786679312162
