Cutler Hammer FD1015 - Molded Case Breaker 15A 277V 1P
Cutler Hammer FD1015 - Molded Case Breaker 15A 277V 1P
Cutler Hammer FD1015 - Molded Case Breaker 15A 277V 1P
Cutler Hammer FD1015 - Molded Case Breaker 15A 277V 1P
Cutler Hammer FD1015 - Molded Case Breaker 15A 277V 1P
Cutler Hammer FD1015 - Molded Case Breaker 15A 277V 1P

Cutler Hammer FD1015 - Molded Case Breaker 15A 277V 1P

Cutler Hammer
Price
Save $696.51
/
Condition
  • Low stock - 4 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer FD1015 is a molded case circuit breaker designed for providing reliable overcurrent protection in commercial and industrial electrical systems. It features a 15A current rating and a 277V AC voltage rating, suitable for single-phase applications. The breaker is constructed with a compact F-frame size measuring 3.38" x 6" x 1.38" (LxHxW) and a bolt-on connection, utilizing a thermal-magnetic trip mechanism for both long-time and instantaneous protection. It is UL Listed and offers an interrupting capacity of 35kA at 277V, operating effectively within a temperature range of -25 to 70 °C. Typical applications include lighting panels, HVAC systems, and branch circuit protection in various facilities.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 277V AC
  • Current Rating: 15A
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 1.38 in (Width)
  • Standards: UL Listed
  • Applications: Commercial/Industrial Lighting, HVAC, Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Single Pole
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 1
  • AIC Rating: 35kA @ 277V
  • Connection: Bolt-On
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI) Trip
  • Frame Size: F Frame
  • Weight: 1.65 lb
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679312100
  • GTIN: 00786679312100
