Square D FC34100 - 100A Molded Case Breaker (65kA AIC, 480V)
Square D FC34100 - 100A Molded Case Breaker (65kA AIC, 480V)
Square D FC34100 - 100A Molded Case Breaker (65kA AIC, 480V)
Square D FC34100 - 100A Molded Case Breaker (65kA AIC, 480V)
Square D FC34100 - 100A Molded Case Breaker (65kA AIC, 480V)
Square D FC34100 - 100A Molded Case Breaker (65kA AIC, 480V)
Square D FC34100 - 100A Molded Case Breaker (65kA AIC, 480V)
Square D FC34100 - 100A Molded Case Breaker (65kA AIC, 480V)

Square D FC34100 - 100A Molded Case Breaker (65kA AIC, 480V)

Square D
Price
Save $-1,354.48
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D FC34100 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial power distribution systems. It features a 100A current rating and a 480V AC voltage rating, housed within a compact F-frame design with an I-Line style plug-in connection for simplified installation. The breaker utilizes a thermal-magnetic trip unit providing both long-time and instantaneous (LI) protection functions and is rated for an interrupting capacity of 65kA at 480V AC. Constructed for demanding environments, it operates reliably across a temperature range of -25 to 70 °C (-13 to 158 °F) and complies with relevant industry standards for safety and performance in commercial and industrial applications.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, I-Line Plug-In
  • Voltage Rating: 480V AC
  • Current Rating: 100A
  • Frame Size: F Frame
  • Poles: 3
  • Phase: 3-Phase
  • AIC Rating: 65kA @ 480V AC
  • Protection Functions: LI (Long-Time and Instantaneous Trip)
  • Connection: I-Line Style Plug-In
  • Operating Temperature Range: -25°C to 70°C (-13°F to 158°F)
  • Family: Square D I-Line
  • Weight: 6 lb


Product Identification
  • UPC: 785901031628
  • GTIN: 00785901422860
