Eaton FAZ-D6/2 - 2-Pole Thermal Magnetic Breaker (6A, 10kA)
Eaton FAZ-D6/2 - 2-Pole Thermal Magnetic Breaker (6A, 10kA)
Eaton FAZ-D6/2 - 2-Pole Thermal Magnetic Breaker (6A, 10kA)
Eaton FAZ-D6/2 - 2-Pole Thermal Magnetic Breaker (6A, 10kA)
Eaton FAZ-D6/2 - 2-Pole Thermal Magnetic Breaker (6A, 10kA)
Eaton FAZ-D6/2 - 2-Pole Thermal Magnetic Breaker (6A, 10kA)

Eaton FAZ-D6/2 - 2-Pole Thermal Magnetic Breaker (6A, 10kA)

Eaton
Price
Save $198.76
/
Condition
  • Low stock - 6 items left
  • Backordered, shipping soon
Call for Price
Eaton FAZ-D6/2 is a molded case circuit breaker designed for supplementary protection in electrical equipment. It provides a 6A current rating and a 10kA interrupting capacity at 277/480V AC for single-phase systems, utilizing a thermal-magnetic trip unit with long-time and instantaneous (LI) protection functions. The compact, two-pole device features a feed-thru connection with lug terminals, measures 1.5 inches cubed, and accommodates wire sizes from 18 AWG to 4 AWG. It is engineered for compliance with UL 1077, CSA C22.2 No. 235, and IEC 60947-2 standards, making it suitable for protecting control circuits, industrial machinery, and panelboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 277/480V AC
  • Current Rating: 6A
  • Dimensions: 1.5 in x 1.5 in x 1.5 in (L/D x H x W)
  • Standards: UL 1077, CSA C22.2 No. 235, IEC 60947-2
  • Applications: Supplementary protection for control circuits, industrial equipment, and panelboards
  • Switch Type: Circuit Breaker
  • Configuration: 2-Pole
  • Connection: Feed-Thru
  • Terminal Connection: Lug
  • Phase: 1
  • AIC Rating: 10kA @ 277/480V
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI (Long Time and Instantaneous)
  • Certification: CSA C22.2 No. 235, IEC 60947-2, UL 1077
  • MCM Size: Min. 18 AWG, Max. 4 AWG
  • Weight: 0.5 lb
  • Family: FAZ Series
  • Country of Origin: Romania


Product Identification
  • UPC: 015082787770
