Eaton FAZ-D40/3 is a three-pole molded case circuit breaker designed for branch circuit and equipment protection in industrial and commercial applications. It provides a 40A current rating and a 10kA interrupting capacity at 277/480V AC, housed in a compact 3-inch cube with a 1 lb weight and lug terminals for secure feed-thru connections. The breaker features thermal-magnetic protection with long-time and instantaneous (LI) trip functions and is constructed to operate reliably across a temperature range of -25°C to 70°C. It complies with key industry standards including UL 1077, CSA C22.2 No. 235, and IEC 60947-2, ensuring suitability for supplementary protection in control panels, HVAC systems, and industrial machinery.

Key Features & Specifications
  • Type: Three-pole, thermal-magnetic molded case circuit breaker with LI (Long-time and Instantaneous) trip functions
  • Voltage Rating: 277/480V AC
  • Current Rating: 40A
  • Dimensions: 3 in x 3 in x 3 in (76.2 mm x 76.2 mm x 76.2 mm)
  • Standards: UL 1077, CSA C22.2 No. 235, IEC 60947-2
  • Applications: Supplementary protection for industrial control circuits, HVAC equipment, and commercial distribution panels
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Poles: 3
  • Connection: Feed-Thru
  • Terminal Connection: Lug
  • Protection: Thermal Magnetic
  • Functions: LI - Long Time and Instantaneous
  • AIC rating: 10kA @ 277/480V
  • Phase: 3
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • MCM Size: Accepts wire sizes from 18 AWG to 4 AWG
  • Weight: 1 lb (0.45 kg)
  • Certification: CSA, UL, IEC
  • Family: FAZ Series
  • Country of Origin: Romania


Product Identification
  • UPC: 015082789002
