Eaton FAZ-D3/2 - 2-Pole Circuit Breaker (3A, 10kA AIC)
Eaton FAZ-D3/2 - 2-Pole Circuit Breaker (3A, 10kA AIC)
Eaton FAZ-D3/2 - 2-Pole Circuit Breaker (3A, 10kA AIC)
Eaton FAZ-D3/2 - 2-Pole Circuit Breaker (3A, 10kA AIC)
Eaton FAZ-D3/2 - 2-Pole Circuit Breaker (3A, 10kA AIC)
Eaton FAZ-D3/2 - 2-Pole Circuit Breaker (3A, 10kA AIC)

Eaton FAZ-D3/2 - 2-Pole Circuit Breaker (3A, 10kA AIC)

Eaton
Price
Save $278.63
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton FAZ-D3/2 is a two-pole molded case circuit breaker designed for supplementary protection in control circuits and equipment. It features a 3A current rating and a 2V voltage rating, housed in a compact 1.5 in x 1.5 in x 2 in (L/D x H x W) enclosure weighing 0.5 lb. The breaker is constructed with lug terminals, supports wire sizes from 18 AWG to 4 AWG, and complies with CSA, IEC, and UL standards including CSA C22.2 No. 235, IEC 60947-2, and UL 1077. Its thermal-magnetic protection with long-time and instantaneous trip functions and a 10kA interrupting rating at 277/480V makes it suitable for industrial applications requiring reliable overcurrent and short-circuit protection in single-phase, feed-through configurations.

Key Features & Specifications
  • Type: Two-pole, molded case, thermal-magnetic circuit breaker with feed-through connection
  • Voltage Rating: 2V
  • Current Rating: 3A
  • Dimensions: 1.5 in (Length/Depth) x 1.5 in (Height) x 2 in (Width)
  • Weight: 0.5 lb
  • Standards: CSA C22.2 No. 235, IEC 60947-2, UL 1077
  • Applications: Supplementary protection for control circuits and industrial equipment
  • Switch Type: Circuit Breaker
  • Configuration: Feed-Thru
  • Phase: 1
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • AIC rating: 10kA@277/480V
  • Connection: Feed-Thru
  • Terminal Connection: Lug
  • MCM Size: Min. Wire Size 18 AWG, Max. Wire Size 4 AWG
  • Certification: CSA C22.2 No. 235, IEC 60947-2, UL 1077
  • Family: FAZ Series
  • Country of Origin: Romania


Product Identification
  • UPC: 015082787732
