Eaton FAZ-D2/3 - 3-Pole Circuit Breaker (2A, 480V)
Eaton FAZ-D2/3 - 3-Pole Circuit Breaker (2A, 480V)
Eaton FAZ-D2/3 - 3-Pole Circuit Breaker (2A, 480V)
Eaton FAZ-D2/3 - 3-Pole Circuit Breaker (2A, 480V)
Eaton FAZ-D2/3 - 3-Pole Circuit Breaker (2A, 480V)
Eaton FAZ-D2/3 - 3-Pole Circuit Breaker (2A, 480V)
Eaton FAZ-D2/3 - 3-Pole Circuit Breaker (2A, 480V)
Eaton FAZ-D2/3 - 3-Pole Circuit Breaker (2A, 480V)
Eaton FAZ-D2/3 - 3-Pole Circuit Breaker (2A, 480V)
Eaton FAZ-D2/3 - 3-Pole Circuit Breaker (2A, 480V)

Eaton FAZ-D2/3 - 3-Pole Circuit Breaker (2A, 480V)

Eaton
Price
Save $409.15
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton FAZ-D2/3 is a molded case circuit breaker designed for supplementary protection of equipment and branch circuits. It provides a 2A current rating and 480V voltage rating for three-phase systems, featuring a compact 2.25 in x 3 in x 3 in footprint and a weight of 0.8 lb with a robust lug terminal connection. The breaker is constructed for compliance with CSA C22.2 No. 235, IEC 60947-2, and UL 1077 standards, utilizing thermal-magnetic protection with LI (Long time and Instantaneous) functions. Its 10kA interrupting rating at 277/480V and feed-thru connection make it suitable for industrial control panels, HVAC systems, and machinery where reliable overcurrent and short-circuit protection is required.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, FAZ Series
  • Voltage Rating: 480V AC
  • Current Rating: 2A
  • Dimensions: 2.25 in (Depth) x 3 in (Height) x 3 in (Width)
  • Standards: CSA C22.2 No. 235, IEC 60947-2, UL 1077
  • Applications: Equipment and Branch Circuit Supplementary Protection
  • Switch Type: Circuit Breaker
  • Configuration: 3-Pole
  • Connection: Feed-Thru
  • Phase: 3
  • AIC Rating: 10kA @ 277/480V
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI (Long Time and Instantaneous)
  • Terminal Connection: Lug
  • MCM Size: Min. 18 AWG, Max. 4 AWG
  • Weight: 0.8 lb
  • Certification: CSA C22.2 No. 235, IEC 60947-2, UL 1077
  • Country of Origin: Romania


Product Identification
  • UPC: 015082788845
  • GTIN: 04015082788841
