Eaton FAZ-D15/3 is a three-pole molded case circuit breaker designed for feeder protection in three-phase industrial and commercial electrical systems. It provides reliable thermal-magnetic protection with a 15A current rating and 480V AC voltage rating, featuring a compact 3-inch cube design with robust lug terminals for secure feed-thru connections. This unit is engineered to meet rigorous international standards including UL 1077, CSA C22.2 No. 235, and IEC 60947-2, ensuring compliance for supplementary protection applications. Its 10kA interrupting rating at 277/480V AC makes it suitable for controlling and protecting branch circuits, panelboards, and industrial machinery where dependable overcurrent and short-circuit protection is required.

Key Features & Specifications
  • Type: Three-pole, thermal-magnetic molded case circuit breaker with Long-time and Instantaneous (LI) trip functions
  • Voltage Rating: 480V AC
  • Current Rating: 15A
  • Dimensions: 3 in x 3 in x 3 in (L x H x W)
  • Weight: 1 lb
  • Standards: UL 1077, CSA C22.2 No. 235, IEC 60947-2
  • Applications: Supplementary protection for branch circuits, panelboards, and industrial control equipment
  • Connection: Feed-Thru
  • Terminal Connection: Lug
  • Phase: 3
  • AIC Rating: 10kA @ 277/480V AC
  • Poles: 3
  • Protection: Thermal Magnetic
  • MCM Size: Accepts wire sizes from 18 AWG to 4 AWG
  • Certification: CSA, UL, IEC


Product Identification
  • UPC: 015082788951
  • Family: FAZ Series
