Eaton FAZ-D13/3 is a three-pole molded case circuit breaker designed for feeder protection in industrial and commercial electrical systems. It provides a 13A current rating and 480V voltage rating with thermal-magnetic protection featuring long-time and instantaneous (LI) trip functions. The compact, 3-inch cube construction with lug terminals and feed-thru connection accommodates wire sizes from 4 to 18 AWG. It complies with UL 1077, CSA C22.2 No. 235, and IEC 60947-2 standards, and its 10kA interrupting rating at 277/480V makes it suitable for panelboards, switchboards, and industrial control panels.
Key Features & Specifications
Type: FAZ Series, Molded Case Circuit Breaker, Thermal Magnetic Protection
Voltage Rating: 480V AC
Current Rating: 13A
Dimensions: 3 in x 3 in x 3 in (L x H x W)
Weight: 1 lb
Standards: UL 1077, CSA C22.2 No. 235, IEC 60947-2
