Eaton FAZ-C6/2 is a two-pole supplementary protector designed for equipment protection in single-phase circuits. It features a 6A current rating and a 10kA interrupting capacity at 277/480V AC, utilizing a thermal-magnetic trip mechanism for long-time and instantaneous (LI) protection. The compact, molded-case unit measures 1.38 in x 1.38 in x 1.5 in, weighs 0.53 lb, and features lug terminals compatible with wire sizes from 18 AWG to 4 AWG. It is certified to UL 1077, CSA C22.2 No. 235, and IEC 60947-2 standards for use as a supplementary protector. This feed-thru configuration breaker is typically applied in industrial control panels, HVAC systems, and machinery where reliable branch circuit protection is required.

Key Features & Specifications
  • Type: FAZ Series, Molded Case, Thermal Magnetic Supplementary Protector
  • Voltage Rating: 277/480V AC
  • Current Rating: 6A
  • Dimensions: 1.38 in (L) x 1.38 in (H) x 1.5 in (W)
  • Standards: UL 1077, CSA C22.2 No. 235, IEC 60947-2
  • Applications: Industrial Control Panels, HVAC, Machinery Protection
  • Switch Type: Circuit Breaker
  • Configuration: Feed-Thru
  • Temp Rating: Standard
  • Shipping Dimensions: Unit Dimensions Apply
  • Phase: 1
  • Voltage: 277/480V AC
  • Amperage: 6A
  • AIC rating: 10kA @ 277/480V AC
  • Connection: Feed-Thru
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI)
  • Frame Size: FAZ
  • Trip Type: Thermal Magnetic
  • Panel Type: Compatible with Standard Mounts
  • Breaker Type: Supplementary Protector
  • MCM Size: 18 AWG to 4 AWG
  • Metal Type: Molded Case
  • Mounting: Standard DIN Rail or Panel Mount
  • Hz: 50/60 Hz
  • Terminal Connection: Lug
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Single-Phase
  • Standards: UL 1077, CSA, IEC
  • Certification: UL 1077, CSA C22.2 No. 235, IEC 60947-2
  • Country of Origin: Romania
  • Weight: 0.53 lb


Product Identification
  • UPC: 015082787541
  • Manufacturer Part Number: FAZ-C6/2
