Eaton FAZ-B15/2 - 2-Pole 15A Circuit Breaker (10kA AIC)
Eaton FAZ-B15/2 - 2-Pole 15A Circuit Breaker (10kA AIC)
Eaton FAZ-B15/2 - 2-Pole 15A Circuit Breaker (10kA AIC)
Eaton FAZ-B15/2 - 2-Pole 15A Circuit Breaker (10kA AIC)
Eaton FAZ-B15/2 - 2-Pole 15A Circuit Breaker (10kA AIC)
Eaton FAZ-B15/2 - 2-Pole 15A Circuit Breaker (10kA AIC)

Eaton FAZ-B15/2 - 2-Pole 15A Circuit Breaker (10kA AIC)

Eaton
Price
Save $240.03
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton FAZ-B15/2 is a molded case circuit breaker designed for supplementary protection of equipment and branch circuits. It provides a 15A current rating and 480V voltage rating for single-phase systems, featuring a compact physical footprint of 3 in x 3.5 in x 1.5 in and a thermal magnetic protection mechanism for both long-time and instantaneous trip functions. The device is constructed with lug terminals for a feed-thru connection and is certified to CSA, UL, and IEC standards including CSA C22.2 No. 235 and UL 1077. It is typically applied in industrial control panels and machinery where reliable overcurrent and short-circuit protection with a 10kA interrupting rating at 277/480V is required.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection
  • Voltage Rating: 480V AC
  • Current Rating: 15A
  • Poles: 2
  • Phase: 1
  • AIC Rating: 10kA @ 277/480V
  • Connection: Feed-Thru
  • Terminal Connection: Lug
  • Functions: Long Time and Instantaneous Trip
  • Dimensions: 3 in (D) x 3.5 in (H) x 1.5 in (W)
  • Weight: 0.5 lb
  • MCM Size / Wire Range: 18 AWG to 4 AWG
  • Standards & Certification: CSA C22.2 No. 235, IEC 60947-2, UL 1077
  • Family: FAZ Series
  • Country of Origin: Romania


Product Identification
  • UPC: 015082787336
  • GTIN: 04015082787332
