Square D FAL22015 - Molded Case Circuit Breaker, 15A 2-Pole
Square D FAL22015 - Molded Case Circuit Breaker, 15A 2-Pole

Square D FAL22015 - Molded Case Circuit Breaker, 15A 2-Pole

Square D
Price
Save $261.56
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D FAL22015 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial and commercial electrical systems. It features a 15A current rating and a 240V AC voltage rating, housed within a compact F-frame measuring 162.6 mm H x 76.2 mm W x 104.9 mm D and weighing 3 lb. The breaker is certified to UL, CSA, and IEC standards and utilizes a thermal-magnetic trip unit with long-time and instantaneous (LI) functions for coordinated protection. Its feed-thru connection and compatibility with 12-4 AWG aluminum or 14-4 AWG copper wire make it suitable for a range of branch circuit applications in panelboards and switchboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, FAL Series
  • Voltage Rating: 240V AC
  • Current Rating: 15A
  • Dimensions: 6.4 in (162.6 mm) H x 3 in (76.2 mm) W x 4.13 in (104.90 mm) D
  • Weight: 3 lb
  • Standards: UL Listed, CSA, IEC
  • Applications: Industrial and Commercial Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 1
  • Amperage: 15A
  • AIC Rating: 10kA @ 240V
  • Connection: Feed-Thru
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Frame Size: F Frame
  • Trip Type: Thermal Magnetic
  • Wire Size: 12-4 AWG (Aluminum), 14-4 AWG (Copper)
  • Certification: UL LISTED, CSA, IEC


Product Identification
  • UPC: 785901254607
  • GTIN: 00785901254607
