Eaton FA5H20 - FA-Type Fuse Switch 20A/600V (UL 248 Compliant)

Eaton FA5H20 is a high-voltage fuse switch designed for circuit protection in industrial power distribution systems. It features a 20A current rating with 600V AC voltage capacity, housed in a durable 4 lb copper-alloy construction with visible blade indicators for safe operation. The unit meets UL 248 and IEC 60269 standards for fuse protection devices. Typical applications include motor control centers, transformer protection, and heavy machinery power management in manufacturing facilities.

Key Features & Specifications

• Type: Cooper Power Series NX FA-type fuse switch with visible disconnect
• Voltage: 600V AC
• Current: 20A
• Dimensions: Standard NX frame size (consult technical drawings for exact measurements)
• Standards: UL 248, IEC 60269
• Applications: Industrial power distribution, motor protection, transformer circuits
• Weight: 4 lb
• Construction: Copper alloy contacts, fiberglass-reinforced housing
• Section: Fuses
• Mounting: Panel-mounted with bolt-on terminals
• Certification: UL listed, CSA certified
