Eaton EHD3050 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial power systems. It features a 50A current rating and a 480V AC voltage rating, housed within a compact 100A frame with dimensions of 3.38" D x 6" H x 4.13" W and a weight of 4.5 lb. This thermal-magnetic breaker offers both long-time and instantaneous (LI) trip functions, achieves a 14kA interrupting rating at 480V, and is compliant with UL, CSA, and IEC standards. Its bolt-on connection with load-side lugs accommodates wire sizes from 14 AWG to 1/0 AWG, making it suitable for installation in motor control centers, switchboards, and enclosed controls from major manufacturers like Allen-Bradley and Rockwell Automation.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 480V AC
  • Current Rating: 50A
  • Frame Size: 100A/F
  • Poles: 3
  • AIC Rating: 14kA @ 480V AC
  • Phase Connection: 3-Phase, ABC
  • Trip Functions: LI (Long-Time and Instantaneous)
  • Connection: Bolt-On, Load Side Lug Terminals
  • Wire Size Range (MCM): 14 AWG to 1/0 AWG
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Weight: 4.5 lb
  • Operating Temperature: -4°F to 158°F (-20°C to 70°C)
  • Standards & Certification: UL Listed, CSA Certified, IEC Rated
  • Compatible Panel Types: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Breaker Type: Standard
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679317143
  • GTIN: 00786679317143
