Eaton EHD3020 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power systems. It features a 20A current rating and a 480V AC voltage rating, housed within a compact 100A frame with dimensions of 3.38" D x 6" H x 4.13" W and a weight of 4.15 lb. The breaker utilizes a thermal-magnetic trip unit with Long-Time and Instantaneous (LI) functions and offers a 14kA interrupting capacity at 480V, complying with UL, CSA, and IEC standards. Its bolt-on connection, load-side lugs, and compatibility with a range of panel types including Allen Bradley and Eaton MCCs make it suitable for switchboards, enclosed controls, and motor control centers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Standard Type
  • Voltage Rating: 480V AC
  • Current Rating: 20A
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Standards: UL Listed, CSA Certified, IEC Rated
  • Applications: Motor Control Centers (MCC), Switchboards, Enclosed Control Panels
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -4°F to 158°F (-20°C to 70°C)
  • Phase: 3
  • AIC Rating: 14kA @ 480V
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI)
  • Frame Size: 100A/F
  • Breaker Type: Standard
  • MCM Size: 14 AWG to 1/0 AWG
  • Terminal Connection: Load Side Lug
  • Phase Connection: ABC
  • Certification: UL Listed, CSA Certified, IEC Rated
  • Weight: 4.15 lb


Product Identification
  • UPC: 786679317068
  • GTIN: 00786679317068
