Eaton EHD2050 - Molded Case Circuit Breaker 50A 480V 2-Pole
Eaton EHD2050 - Molded Case Circuit Breaker 50A 480V 2-Pole
Eaton EHD2050 - Molded Case Circuit Breaker 50A 480V 2-Pole
Eaton EHD2050 - Molded Case Circuit Breaker 50A 480V 2-Pole

Eaton EHD2050 - Molded Case Circuit Breaker 50A 480V 2-Pole

Eaton
Price
Save $764.57
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Eaton EHD2050 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial power distribution systems. It features a 50A current rating and a 480V AC voltage rating, housed within a compact 3.38" x 6" x 2.75" (LxHxW) frame with a bolt-on connection and load side lug terminals. This thermal magnetic breaker is constructed for durability with an operating temperature range of -25 to 70 °C and complies with UL, CSA, and IEC standards. Its 14kA interrupting rating at 480V and long-time plus instantaneous (LI) trip functions make it suitable for use in motor control centers, switchboards, and enclosed controls from manufacturers like Allen-Bradley, Eaton, and Rockwell Automation.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 480V AC
  • Current Rating: 50A
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 2.75 in (Width)
  • Standards: UL Listed, CSA Certified, IEC Rated
  • Applications: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Switch Type: Standard
  • Configuration: 2-Pole
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Shipping Dimensions: 3.38 in x 6 in x 2.75 in
  • Phase: 1
  • Voltage: 480V
  • Amperage: 50A
  • AIC rating: 14kA @ 480V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Frame Size: 100A/F
  • Trip Type: Thermal Magnetic
  • Panel Type: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Breaker Type: Standard
  • MCM Size: Min. 14 AWG, Max. 1/0 AWG
  • Mounting: Bolt-On
  • Hz: 50/60 Hz
  • Terminal Connection: Load Side Lug
  • Frequency Rating: 50/60 Hz
  • Phase Connection: ABC
  • Compatible Frames: Series C
  • Certification: UL Listed, CSA Certified, IEC Rated


Product Identification
  • UPC: 786679317471
  • GTIN: 00786679317471
