Cutler Hammer EHD2035 - 35A Molded Case Circuit Breaker (480V, 14kA AIC)
Cutler Hammer EHD2035 - 35A Molded Case Circuit Breaker (480V, 14kA AIC)
Cutler Hammer EHD2035 - 35A Molded Case Circuit Breaker (480V, 14kA AIC)
Cutler Hammer EHD2035 - 35A Molded Case Circuit Breaker (480V, 14kA AIC)

Cutler Hammer EHD2035 - 35A Molded Case Circuit Breaker (480V, 14kA AIC)

Cutler Hammer
Price
Save $1,013.47
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Cutler Hammer EHD2035 is a molded case circuit breaker designed to provide reliable overcurrent protection for industrial electrical systems. It features a 35A current rating and a 480V AC voltage rating, housed within a compact, bolt-on design measuring 3.38" x 6" x 2.75" (LxHxW) and weighing 3 lb. This thermal magnetic breaker offers both long-time and instantaneous (LI) trip functions with a 14kA interrupting capacity at 480V, and it is constructed for operation in temperatures from -25°C to 70°C. It complies with UL, CSA, and IEC standards, making it suitable for integration into a variety of panel types including switchboards, motor control centers (MCCs), and enclosed controls.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 480V AC
  • Current Rating: 35A
  • Frame Size: 100A/F
  • Poles: 2
  • AIC Rating: 14kA @ 480V AC
  • Phase: 1
  • Phase Connection: ABC
  • Trip Functions: LI (Long Time and Instantaneous)
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 2.75 in (Width)
  • Weight: 3 lb
  • Terminal Connection: Load Side Lug
  • Wire Size Range: 14 AWG to 1/0 AWG
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Standards & Certification: UL Listed, CSA Certified, IEC Rated
  • Compatible Panel Types: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Breaker Type: Standard
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679317457
  • GTIN: 00786679317457
