Westinghouse EHD2025 - Molded Case Circuit Breaker 25A 480V 2-Pole
Westinghouse EHD2025 - Molded Case Circuit Breaker 25A 480V 2-Pole
Westinghouse EHD2025 - Molded Case Circuit Breaker 25A 480V 2-Pole
Westinghouse EHD2025 - Molded Case Circuit Breaker 25A 480V 2-Pole

Westinghouse EHD2025 - Molded Case Circuit Breaker 25A 480V 2-Pole

Cutler Hammer
Price
Save $770.66
/
Condition
  • Low stock - 10 items left
  • Backordered, shipping soon
Call for Price
Westinghouse EHD2025 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 25A current rating and a 480V AC voltage rating within a compact 100A frame size, constructed with a durable thermal-magnetic trip unit for LI (Long-time and Instantaneous) protection. The breaker's physical design measures 3.38 in (L) x 6 in (H) x 2.75 in (W) and utilizes a bolt-on connection with load side lugs compatible with wire sizes from 14 AWG to 1/0 AWG. It complies with major industry standards, including UL Listing, CSA Certification, and IEC ratings, ensuring suitability for global applications. Typical installations include Allen Bradley or Eaton motor control centers (MCCs), Rockwell Automation enclosed controls, and various switchboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Standard Type
  • Voltage Rating: 480V AC
  • Current Rating: 25A
  • Frame Size: 100A/F
  • Poles: 2
  • AIC Rating: 14kA @ 480V
  • Phase: 1
  • Connection: Bolt-On
  • Terminal Connection: Load Side Lug
  • Functions: LI (Long Time and Instantaneous)
  • Protection: Thermal Magnetic
  • Panel Type: Compatible with Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Phase Connection: ABC
  • Breaker Type: Standard
  • Standards: UL Listed, CSA Certified, IEC Rated
  • Certification: UL Listed, CSA Certified, IEC Rated
  • Dimensions: 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
  • Weight: 3 lb
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • MCM Size: Min. Wire Size 14 AWG, Max. Wire Size 1/0 AWG
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679317433
  • GTIN: 00786679317433
