Cutler Hammer EHD2020 - Molded Case Circuit Breaker 20A 480V 2-Pole
Cutler Hammer EHD2020 - Molded Case Circuit Breaker 20A 480V 2-Pole
Cutler Hammer EHD2020 - Molded Case Circuit Breaker 20A 480V 2-Pole
Cutler Hammer EHD2020 - Molded Case Circuit Breaker 20A 480V 2-Pole

Cutler Hammer EHD2020 - Molded Case Circuit Breaker 20A 480V 2-Pole

Cutler Hammer
Price
Save $724.32
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer EHD2020 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial power distribution systems. It features a 20A current rating and a 480V AC voltage rating, housed within a compact 100A frame with dimensions of 3.38" D x 6" H x 2.75" W and a weight of 2.9 lb. This thermal-magnetic breaker, offering 14kA interrupting capacity at 480V, is CSA Certified, IEC Rated, and UL Listed for compliance, and is typically applied in motor control centers, switchboards, and enclosed controls.

Key Features & Specifications
  • Type: EHD Series C, Molded Case, Thermal Magnetic Protection, Standard Breaker
  • Voltage Rating: 480V AC
  • Current Rating: 20A
  • Frame Size: 100A/F
  • Poles: 2
  • Connection: Bolt-On, Load Side Lug Terminal
  • AIC Rating: 14kA @ 480V AC
  • Phase: 1
  • Phase Connection: ABC
  • Trip Functions: LI (Long-Time and Instantaneous)
  • Dimensions: 3.38 in (D) x 6 in (H) x 2.75 in (W)
  • Weight: 2.9 lb
  • Wire Size Range: 14 AWG to 1/0 AWG
  • Operating Temperature: -4°F to 158°F (-20°C to 70°C)
  • Standards & Certification: CSA Certified, IEC Rated, UL Listed
  • Compatible Panel Types: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse


Product Identification
  • UPC: 786679317426
  • GTIN: 00786679317426
