Eaton EHD2015 - Molded Case Circuit Breaker 15A 480V 2-Pole
Eaton EHD2015 - Molded Case Circuit Breaker 15A 480V 2-Pole
Eaton EHD2015 - Molded Case Circuit Breaker 15A 480V 2-Pole
Eaton EHD2015 - Molded Case Circuit Breaker 15A 480V 2-Pole

Eaton EHD2015 - Molded Case Circuit Breaker 15A 480V 2-Pole

Eaton
Price
Save $567.96
/
Condition
  • Low stock - 7 items left
  • Backordered, shipping soon
Call for Price
Eaton EHD2015 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial electrical systems. It features a 15A current rating and a 480V AC voltage rating, housed within a compact 100A frame with dimensions of 3.38" D x 6" H x 2.75" W and a weight of 2.7 lb. The breaker is constructed with bolt-on connections and load side lugs, supporting wire sizes from 14 AWG to 1/0 AWG, and operates on a single-phase system with an ABC phase connection. It complies with major industry standards including UL Listing, CSA Certification, and IEC ratings, ensuring suitability for a wide range of panel types such as Allen Bradley MCCs, Eaton MCCs, switchboards, and enclosed controls. Its thermal-magnetic protection with long-time and instantaneous (LI) trip functions and a 14kA interrupting rating at 480V makes it ideal for safeguarding motors, feeders, and branch circuits in demanding environments, with an operational temperature range from -4°F to 158°F.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Standard Type, Thermal-Magnetic Protection with Long-Time and Instantaneous (LI) Trip
  • Voltage Rating: 480V AC
  • Current Rating: 15A
  • Frame Size: 100A/F
  • Poles: 2
  • Connection: Bolt-On
  • Terminal Connection: Load Side Lug
  • AIC Rating: 14kA @ 480V
  • Phase: 1
  • Phase Connection: ABC
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 2.75 in (Width)
  • Weight: 2.7 lb
  • MCM Size / Wire Range: 14 AWG to 1/0 AWG
  • Temp Rating: -4°F to 158°F (-20°C to 70°C)
  • Standards & Certification: UL Listed, CSA Certified, IEC Rated
  • Panel Type Compatibility: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679317419
  • GTIN: 00786679317419
