Cutler Hammer EGB3030FFG - 30A 3-Pole Molded Case Circuit Breaker

Price
Regular price $455.98
Regular price $1,126.28 Sale price $455.98
Save $670.30
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Cutler Hammer EGB3030FFG is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power distribution systems. It features a 30A current rating and a 480V AC voltage rating, housed in a compact, durable enclosure measuring 2.99" x 5.5" x 3" (LxHxW) and weighing 2.88 lb. The breaker is certified to UL, CSA, IEC, and CE standards and operates effectively across a temperature range of -25°C to 70°C (-13°F to 158°F). Its thermal-magnetic protection with long-time and instantaneous trip functions and an 18kA interrupting rating at 480V makes it suitable for protecting feeders and branch circuits in commercial and industrial panelboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Series G, EGB Type, Thermal-Magnetic Protection
  • Voltage Rating: 480V AC
  • Current Rating: 30A
  • Dimensions: 2.99 in (Depth) x 5.5 in (Height) x 3 in (Width)
  • Standards: UL Listed, CSA Certified, IEC Rated, CE Marked
  • Applications: Industrial power distribution, panelboard protection
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 3
  • Poles: 3
  • Connection: Feed-Thru
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • AIC rating: 18kA @ 480V
  • Wire Size: 14 to 3/0 AWG
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Weight: 2.88 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782114876312
  • GTIN: 00782114876312
