Siemens ED63S100A - Molded Case Circuit Breaker 100A 600V
Siemens ED63S100A - Molded Case Circuit Breaker 100A 600V

Siemens ED63S100A - Molded Case Circuit Breaker 100A 600V

Siemens
Price
Save $3,096.32
/
Condition
  • Low stock - 5 items left
  • Backordered, shipping soon
Call for Price
Siemens ED63S100A is a molded case circuit breaker from the Sentron Series designed to provide reliable overcurrent and short-circuit protection for three-phase industrial power distribution systems. It features a 100A continuous current rating and a 600V AC voltage rating, housed within a compact, durable ED frame with a bolt-on connection for secure installation. This thermal-magnetic breaker, which offers both long-time and instantaneous trip functions, is UL Listed and IEC Certified for compliance with international safety standards, and it operates effectively across a temperature range of -25°C to 70°C. Its 25kA interrupting capacity at 480V AC makes it suitable for protecting feeders and branch circuits in commercial and industrial panelboards, compatible with copper or aluminum conductors from AWG 10 to 1/0.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Frame Size: ED Frame
  • Poles: 3
  • Connection: Bolt-On
  • Wire Size: AWG 10 to AWG 1/0, Cu/Al
  • AIC Rating: 25kA @ 480V AC
  • Phase: 3
  • Certification: UL Listed, IEC Certified
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Weight: 3.699 lb
  • Functions: Long Time and Instantaneous Trip
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643211056
  • GTIN: 00783643211056
